Basic Info.
| Max.Head | <10m | Max.Capacity | >400 L/min |
| Driving Type | Motor | Impeller Number | Single-Stage Pump |
| Working Pressure | Low Pressure Pump | Influent Type of Impeller | Single Suction Pump |
| Position of Pump Shaft | Horizontal Pump | Pump Casing Combined | Horizontal Split Pumps |
| Mounting Height | Suction Centrifugal | Impeller | Open |
| Usage | Pump, Pumps, Circulating Pump | Standard | GB/T13008 |
| Temperature | ~200 Degree | Pressure | ~0.6MPa |
| Head | 1.5~7.0m | Rotation Speed | 320/360/380/400/500/730/980 |
| Capacity | 3~2600m3/H | Transport Package | Plywood Box |
| Specification | 1000.00cm * 2000.00cm * 1000.00cm | Trademark | haishi |
| Origin | Jiangsu, China | HS Code | 8413709990 |
| Production Capacity | 5000 |
Products Description
Chemical Dosing Circulation Pump: Typical Service Life
A Chemical Dosing Circulation Pump is a key component in industries where accurate and continuous chemical delivery is critical. Understanding its service life is essential for planning maintenance and replacement schedules.
Average Lifespan
Under normal operating conditions, a high-quality Chemical Dosing Circulation Pump can last between 5 to 10 years. However, the exact lifespan depends heavily on several factors such as pump material, chemical type, operating environment, and maintenance practices.
Factors That Affect Longevity
- Chemical Properties: Strong acids or corrosive chemicals may shorten the pump's life unless corrosion-resistant materials like PTFE or stainless steel are used.
- Maintenance: Regular inspection of seals, valves, and diaphragms can significantly extend the pump's service life.
- Operating Conditions: Running pumps continuously at high pressure or temperature without adequate cooling or lubrication can reduce lifespan.
- Installation Quality: Proper alignment, correct electrical connection, and using the right accessories also contribute to a longer working life.
Conclusion
With the right material selection and routine maintenance, Chemical Dosing Circulation Pumps can offer long-term, reliable performance for most industrial applications. Investing in regular upkeep is key to maximizing their operational lifespan.
| Demonstration Of The Type | Range Of Application | Performance Parameter |
| HZX-800 HZX(FJX): Series code 800: Nominal diameter of the impeller | For new energy, MVR device, ammonium phosphate, phosphoric acid, vacuum salt, Forced circulation of evaporators in alumina, caustic soda and other chemical industries, It can also be used as a circulating pump for crystallization and reactor. Can also be used in chemical, petrochemical, oil refinery, power plant, paper,Pulp and alkali, urban water supply and other industries. Suitable for conveying normal temperature or medium temperature neutral or corrosive, clean or containing particles of media. |
Flow rate: ~50000m³/h Head: ~8m Speed: 380~980r/min Design pressure: ~ 1.6MPa Operating temperature: -20ºC~150ºC |
1. Pump body 2. Impeller hub 3. Impeller blade 4. Protective sleeve 5. Shafting6. Shaft seal 7. Non-drive end bearing 8. Bearing box 9. Oil pan 10. Drive end bearing
Company profile
We offer integrated solutions from embryo casting to complete machine with short lead time and controlled quality.
Main product
workshop
exhibition
Certification certificate
Cooperative brand
Packaging & Transportation
FAQ
Q: How do you ensure pump quality before shipment?
A: Each pump undergoes strict testing including pressure, performance, and vibration tests.
Q: Are magnetic drive pumps maintenance-free?
A: Magnetic drive pumps have no mechanical seal, so they require very minimal maintenance.
Q: Can you design a pump based on our technical drawing?
A: Yes, we support custom pump production based on customer specifications and drawings.
Q: Do your chemical pumps support variable frequency control?
A: Yes, most of our pumps are compatible with VFDs for flexible speed adjustment.
Q: Can you provide 3D drawings or CAD files for installation planning?
A: Yes, we provide 2D/3D models upon request for engineering purposes.
Q: What's the maximum flow rate of your pumps?
A: Flow rates range from a few liters per minute to thousands of cubic meters per hour.
Q: What's the lead time for large custom pump orders?
A: Usually 25–35 days depending on the size and complexity of the pump.
